The electric drive truck mounted drilling rig is based on the conventional diesel engine driven truck mounted drilling rig,
which changes the drawworks and rotary table from diesel engine drive to electric drive or oil and electricity dual drive. It
combines the advantages of compact structure, fast transportation of conventional truck mounted rig and high efficiency,
energy saving and environmental protection of electric drive drilling rig.
Product Features:
1.The main motor adopts AC frequency conversion speed regulation control to realize stepless speed regulation.
2.The control system adopts PLC control, which can be matched with automatic equipment to realize intelligent and
automatic operation.
3.It is equipped with heavy safety protection such as over roll anti-collision, electronic anti-collision and stall protection,
which is safer and more reliable.
4.According to the power supply of different well pads, pure electric drive or oil electric double drive can be designed.
5.The electric, air and hydraulic circuit systems are controlled centrally, and the main components are selected the
well-known brand.
6.The chassis engine is an internationally famous brand, which can meet the emission level of national VI at most.
7.Products with special environmental requirements such as alpine, desert, plateau and beach can be customized.
