2.Power System: high-speed diesel engine, hydraulic mechanical drive, engine 175KW~257Kw, high performance,standard layout BY350 hydrodynamic transmission.The mast is structural mast, the hydraulic cylinder carries out lifting.
3.Slant degree: 5.5°, the mast uppelbody bearing unit equipped with cylinder bearing organ that is the turning block type, which structure is simple safe and reliable.
4.Drawworks: Single drum structure, maximum capacity120KN, band or disc brake, air cooling structure.Reversing valve adopted pneumatic controland manual duplexing Structure, simple operating andpipeline layout.
5.Rated working pressure 14Mpa
Mean application
1.Well repairing: up and down the tubing, sucker rod, deep-well pump and other underground tools2.Cleaning: up and down the packer and salving the bottom things.
3.Drilling the cement plug and other work over treatment.
4.Formation testing: Oil Well swabbing.
5.Well head setting and jack-up etc.subsidiary occupation.
